AMD B650

AM5

1x USB-C (USB 3.2 Gen 2×2)
1x USB-C (USB 3.1/3.2 Gen 2)
6x USB-A (USB 3.1/3.2 Gen 2)
4x USB-A (USB 2.0)

No

1x HDMI
1x DisplayPort

5x 1/8″ / 3.5 mm
1x S/PDIF

1x Intel 2.5Gigabit

2x Connector

BIOS Flashback, Clear CMOS

4x 288-Pin

DDR5 4800, 5000, 5200, 5400, 5600, 5800, 6000, 6200, 6400 MT/s

128 GB

Dual Channel

Non-ECC, ECC Unbuffered

4x SATA III

1x M.2 (M Key) 2242, 2260, 2280 (PCIe 5.0 x4)
2x M.2 (M Key) 2242, 2260, 2280 (PCIe 4.0 x4)
1x M.2 (M Key) 2242, 2260, 2280, 22110 (PCIe 5.0 x4)

No

RAID 0, 1, 10 (M.2)

2x PCIe 5.0 x16
1x PCIe 4.0 x16 (x4 mode)

1x USB 3.1/3.2 Gen 2 Header (Supports 1 USB-C Port)
1x USB 3.0 / 3.1/3.2 Gen 1 Header (Supports 2 USB-A Port)
2x USB 2.0 Header (Supports 4 USB-A Port)

2x 4-Pin CPU
5x 4-Pin System
1x Thermal Sensor

1x 4-Pin Pump

1x 24-Pin Mainboard
2x 8-Pin ATX

Chassis Intrusion

4x RGB

CPU Overclock

1x Thunderbolt Header

256 Mb

AAFP, USB 3.0 / 3.1/3.2 Gen 1, USB 3.1/3.2 Gen 2

SupremeFX ALC4080 (7.1-Channel)

Savitech SV3H712

Wi-Fi 6E (802.11ax) with MU-MIMO Support

5.2

Windows 10
Windows 11

ATX

9.6 x 12″ / 24.4 x 30.5 cm

5.025 lb

13.5 x 11.2 x 3.1″
